Name: HIKROBOT Frame Grabbers
Brand: HIKROBOT
SKU: MV-GC1002-V2
Availability: InStock

Product introduction

Functional characteristics

Supports GigE Vision V2.0 protocol, and the maximum rate of a single network port can reach 10Gbps
Bus Indicator and Channel Indicator provide real-time feedback on Frame Grabbers status
Support for reissuing contracts and Event events
Rich I/O Interface, integrated multiple inputs and outputs
Provide SDK for secondary development
Follow GenlCamStandard

Ordering Model

MV-GT1004

Dimensions

* Data related to the product may be generated due to environmental factors and other factors Differences , the company will not bear the consequences arising therefrom.

Ordering Model

MV-GT1004

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Dimensions drawings can be downloaded from the product manual to view, or contact sales for CAD / PDF drawings.

Detailed parameters

Ordering Model MV-GT1004

Model

Model	MV-GT1004
Name	Four electric ports and 10 million images Frame Grabbers

Memory

Onboard Memory

2 GB DDR3-RAM

Host Interface

Bus Interface	PCI-E gen2 × 8
Bus Interface Performance	3900 MB/s(peak transmission bandwidth), 3350 MB/s(persistent transmission bandwidth)
Bus Indicator	1

Camera Interface

Standard	GigE Vision V2.0
Connector	4 × RJ45
Supported Camera Type	Gigabit, 100 Gigabit Ethernet Industrial Cameras
Supported Camera Quantity	Up to 4 (total bandwidth of 27 Gbps)
Camera Interface Rate	10 Gbps
Flow Channel	4
Channel Indicator	4 pairs

Processing Functions

Pixel Format

Mono 8/10/10p/12/12p/16 Bayer 8/10/10p/12/12p YUV422Packed,YUV422_YUYV_Packed RGB 8,BGR 8

General-Purpose I/O

I/O Type	8 configurable inputs/outputs, single-ended/differential compatible Line 0/1/4/5/6/7 supports 3.3 to 12 V input and 3.3 V output Line 2/3 supports 3.3 to 26 V input and 3.3 V output
Connector	9 pin needle arrangement

Electrical

Typical Power Consumption

24 W

Mechanical
