HIKROBOT Frame Grabbers

MV-GX1104

We are a global provider of machine vision, mobile robots, and articulated robot products and solutions

Consulting quotation
MV-GX1104

Product introduction

Functional characteristics

  • Supports CXP-6 protocol, with a maximum rate of 6.25Gbps per channel

  • Support PoCXP, a single channel can provide up to 13W

  • Bus Indicator and Channel Indicator provide real-time feedback on Frame Grabbers status

  • Rich I/O Interface, integrated multiple inputs and outputs

  • Provide SDK for secondary development

  • Follow GenIcam Standard



Ordering Model

MV-GX1104


Dimensions

* Data related to the product may be generated due to environmental factors and other factors Differences , the company will not bear the consequences arising therefrom.

Ordering Model

MV-GX1104

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Dimensions drawings can be downloaded from the product manual to view, or contact sales for CAD / PDF drawings.

Detailed parameters

Ordering Model MV-GX1104
Model
Model MV-GX1104
Name 4-port CXP-6 Frame Grabber
Memory
Onboard Memory 4 GB DDR4-RAM
Host Interface
Bus Interface PCI-E gen3 × 4
Bus Interface Performance 3400 MB/s(peak transmission bandwidth), 3350 MB/s(persistent transmission bandwidth)
Bus Indicator 1
Camera Interface
Standard CoaXPress 1.0/1.1
Connector 4 × DIN 1.0/2.3
Power output PoCXP, single channel can provide up to 13W@24VDC
Supported Camera Type CXP-6InterfaceIndustrial Cameras
Supported Camera Quantity Up to 4
Camera Interface Rate 1.25/2.5/3.125/5/6.25Gbps(CXP-1/2/3/5/6)
Flow Channel 4
Channel Indicator 4
Processing Functions
Pixel Format Mono 8/10/12/16 Bayer 8/10/12/16 RGB8
General-Purpose I/O
I/O Type 11 configurable inputs/outputs, single-ended/differential compatible Baffle I/O:Line 0~6 supports 3.3 ~ 24 V input and output Pin I/O:Line 7~10 supports 3.3 ~ 24 V input and output
Connector Baffle I/O: DB15 male Pin arrangement I/O:9 pin pin arrangement (2.54 mm spacing, 2 × 5,10 pin blind hole)
Electrical
Typical Power Consumption 11.1 W(excluding PoCXP)
Mechanical
Dimensions 181 mm × 126.3 mm × 21.6 mm
Temperature Operating Temperature0 ~ 55°C, Storage Temperature-20 ~ 70°C
Humidity 10% ~ 95% RH Non-condensing
General Specifications
Software MVS
Operating System Windows 7/10/11,Linux supports 64-bit Ubuntu 18.04 ~ 24.04
Certification RoHS,CE,KC

Data download

Product manual· SDK ·Development documentation
