HIKROBOT Full Range of Industrial Area Scan Cameras

MV-CL16K5-40F2C-PRO

16384 × 12, 2LC Fiber Interface, Color

Consulting quotation
MV-CL16K5-40F2C-PRO

Product introduction

Functional characteristics

  • Rich ISP image processing technologies, such as manual adjustment of Gamma correction, flat field correction, color correction, etc.

  • RGB true color imaging, multiple flexible exposure and acquisition methods, support single line/2-TDI/4-TDI Imaging Mode

  • Provides high-bandwidth transmission from dual XoFLink optical ports, and the basic line frequency can reach up to 40 kHz

  • Frame Grabbers supporting transmission solution, which combines high-speed transmission and flexible image/Light Source linkage acquisition

  • Mechanical design is compact, Flexible installation with multiple mounting holes



Ordering Model

MV-CL16K5-40F2C-PRO


Dimensions

* The data involved in the product may cause differences due to environmental factors and other factors, and the company will not bear the consequences.

Ordering Model

MV-CL16K5-40F2C-PRO

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Dimensions drawings can be downloaded from the product manual to view, or contact sales for CAD / PDF drawings.

Detailed parameters

Ordering Model MV-CL16K5-40F2C-PRO
Model
Model MV-CL16K5-40F2C-PRO
Name 16k5μm, 12-line true color, 4TDI, 4 light time-sharing
Performance
Sensor Type CMOS
Pixel Size 5 μm × 5 μm
Resolution 16384 × 12
Imaging Mode Support 1-Line,2-TDI,4-TDI, support 4 groups of exposure polling
Max. Line Rate 40 kHz
Transmission mode 1Link, 2Link
Dynamic Range 62.6 dB
SNR 39.3 dB
Gain 1.0×,1.3×,2.0×,4.0×
Exposure Time 3 μs ~ 10 ms
Shutter Mode Support automatic exposure, manual exposure, and one-click exposure; Support fixed Exposure Time and Pulse Width control Exposure Time
Mono/Color Color
Pixel Format RGB 8,BGR 8,Mono 8/10/12,Bayer RG 8/10/12
Binning 1 × 1,1 × 2,1 × 4,2 × 1,2 × 2,2 × 4,4 × 1,4 × 2,4 × 4
Mirror Support horizontal Mirror
Trigger Mode External triggering, internal triggering
External Trigger Mode Line triggering
Electrical
Data Interface 2LC Optical Fiber Interface
Digital I/O 12-pin P10Connector provides Power Supply and I/O:4 configurable inputs/outputs (Line 0/1/3/4), supports single-ended/differential
Power Supply 24 VDC
Typical Power Consumption 26.2 W@24 VDC
Mechanical
Lens Mount M90*1,Flange Back Focal Length12 mm; Can be transferred to the F port Lenses
Dimensions 99 mm × 99 mm × 81.7 mm
Weight approx. 870 g
IP Rating IP40 (When Lenses and Cables are installed correctly)
Temperature Operating Temperature-20 to 50°C, Storage Temperature-30~80°C
Humidity 5%~90%RH No condensation
General Specifications
Software MVS
Operating System Windows 7/10 32/64bits,Windows 11 64bits,Linux 32/64bits
Protocol / Standard XoFLink,GenlCam
Certification CE,RoHS,KC

Data download

Product manual· SDK ·Development documentation
