Name: HIKROBOT Style Series Lighting
Brand: HIKROBOT
SKU: MV-LRSS-H-80-W
Availability: InStock

MV-LDSS-H-8-3-R

HIKROBOT-style MV-*-H-*Light Source currently covers Ring Lights MV-LRDS-H-*-W, MV-LRSS-H-*-W series, strip-shaped Light SourceMV-LLDS-H-*-*-W series and Line Lights MV-LTDS-H-*-W series. The new family-style design is efficient and stable, meeting the needs of most conventional visual lighting applications.

Product introduction

Functional characteristics

The light outlet adopts a special light guide column with concentrated brightness
Mechanical design with compact size and efficient heat dissipation
Can be paired with Lenses series such as Telecenter

Ordering Model

MV-LDSS-H-8-3-R

Dimensions

* Data related to the product may be generated due to environmental factors and other factors Differences , the company will not bear the consequences arising therefrom.

Ordering Model

MV-LDSS-H-8-3-R

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Dimensions drawings can be downloaded from the product manual to view, or contact sales for CAD / PDF drawings.

Detailed parameters

Ordering Model MV-LDSS-H-8-3-R

Model

Model	MV-LDSS-H-8-3-R
Name	Standard Point Light Source, red

Performance

Color	Red
Central Irradiance	> 7K lux@WD=100 mm
Optimal Working Distance	65 ~ 200 mm
Wavelength	620 ~ 630 nm
Color Temperature	/

Electrical

Power	1.7 W
Interface Type	SMR-03V-B

Mechanical

Dimensions	59 mm × Ø24 mm
Light outlet diameter	Ø 8 mm
Weight	75 g
Power Cable Length	1 m
Temperature	Operating Temperature0 ~ 40°C, Storage Temperature-20 ~ 60°C
Humidity	20 ~ 90%RH Non-condensing
