Name: HIKROBOT IDP Series Handheld PDA
Brand: HIKROBOT
SKU: MV-IDP3204/32G
Availability: InStock

MV-IDP3204/64G

Industrial-grade intelligent handheld terminal uses self-developed image code reading modules and self-developed algorithms to efficiently read mainstream one-dimensional and two-dimensional codes. Built-in self-developed deep learning algorithm, with functions such as continuous scanning code, precise scanning code, OCR recognition, and batch scanning code.

Product introduction

Functional characteristics

Using self-developed deep learning algorithms, it can efficiently read industry trouble codes, such as broken frame, ink overflow, ink shortage, film coating, and stain codes
Eight-core 2.0GHzProcessor, based on Android 13.0 Operating System
4.0-inch Display, 800×480 screen Resolution
High-protection industrial and Mechanical design, IP65 protection and multiple drops of 1.5 meters
4850 mAh large-capacity battery ensures long battery life, and supports fast charging
Supports fast roaming function, Wi-FiPerformance is powerful

Ordering Model

MV-IDP3204/64G

* The data involved in the product may cause differences due to environmental factors and other factors, and the company will not bear the consequences arising therefrom.

Ordering Model

MV-IDP3204/64G

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Dimensions drawings can be downloaded from the product manual to view, or contact sales for CAD / PDF drawings.

Detailed parameters

Ordering Model MV-IDP3204/64G

Model

Model	MV-IDP3204/64G
Name	Eight-core 4-inch keyboard smart Mobile device

Performance

Barcode Type	One-dimensional code:Code 11,Code 39,Code 93,Code 128,GS1,EAN,UPC-A,UPC-E,Interleaved 2 of 5,Codabar,Matrix 2 of 5,Industrial 2 of 5,Datalogic 2 of 5 (China Post),MSI Plessey,Pharmacode Matrix QR Code:Data Matrix,QR Code,Micro QR Code,Aztec,Han Xin Code,MaxiCode,Data Matrix ECC140 Stacked QR code:MicroPDF,PDF417
Min. Barcode Resolution	3 mil
Inspection Angle	Horizontal 42°, vertical 28°
Field of View Angle	Tilt angle ±60°, tilt angle ±45°, rotation angle 360°
Depth of Field	Code 39(10 mil):40 mm ~ 340 mm Code 39(25 mil):70 mm ~ 480 mm Code 128(5 mil):70 mm ~ 200 mm Code 128(100 mil):0 ~ 1450 mm1 Data Matrix(10 mil):60 mm ~ 200 mm QR Code(20 mil):45 mm ~ 370 mm QR Code(100 mil):0 ~ 1000 mm1
Processor	8-core 2.0 GHzProcessor
Memory	RAM 4 GB,ROM 64 GB
Expansion card slot	TF card, support up to 512 GB
Operating System	Android 13.0
SIM	1 Nano-SIM card slot
Camera	Rear camera: 8 megapixels (color zoom)
Sensor	Gravity Sensor, light Sensor, distance Sensor
Display	4.0-inch Display(800×480)
Touchscreen	Capacitive touch, glove mode support
Audio	Built-in speakers, built-in single microphone
Keyboard	Front:23 buttons, 1 power button Side:2 side scan buttons, 1 custom button

NFC

Operating frequency	13.56 MHz
Protocol Standard	ISO14443A/B,ISO15693
Reading distance	Within 3 cm

Electrical

Interface	Type-C,USB 2.0,OTG
Battery	4850 mAh, detachable battery Default equipped with 5V, 2A adapter

Communication Method

Mobile communications	2G:GSM B3/B5/B8 3G:WCDMA B1/B5/B8 4G:TDD B34/B38/B39/B40/B41,FDD-LTE B1/B3/B5/B8
Wi-Fi	IEEE 802.11 a/b/g/n/ac
Bluetooth	BT5.0
Positioning	GPS, Beidou,GLONASS

Mechanical

Dimensions	165.9 mm × 69.4 mm × 16.8 mm
Weight	265 g(including battery)
IP Rating	IP65
Temperature	Operating Temperature:-20 ~ 50°C StorageTemperature:-40 ~ 60°C
Humidity	5 ~ 95%RH non-condensation
Drop specifications	1.5m cement ground drop resistance
Electrostatic protection	±15 KV(air discharge),±8 KV(contact discharge)
