Name: HIKROBOT CH Series Industrial Area Scan Cameras
Brand: HIKROBOT
SKU: MV-CH040-A0CM
Availability: InStock

Product introduction

Functional characteristics

Supports automatic or manual adjustment of Gain, Exposure Time, white balance, Gamma, LUT correction, etc.
Support custom ROI, horizontal Mirror and vertical Mirror
Support hard trigger, soft trigger and free running mode
Compatible with USB3 Vision protocol and GenICamStandard, and can seamlessly connect with third-party Software Platforms

Ordering Model

MV-CH089-10UC

Dimensions

* Data related to the product may be generated due to environmental factors and other factors Differences , the company will not bear the consequences arising therefrom.

Ordering Model

MV-CH089-10UC

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Dimensions drawings can be downloaded from the product manual to view, or contact sales for CAD / PDF drawings.

Detailed parameters

Ordering Model MV-CH089-10UC

Model

Model	MV-CH089-10UC
Name	8.9 megapixel USB 3.0 Area Array Camera, IMX267, Color

Performance

Sensor Type	CMOS, global shutter
Sensor Model	Sony IMX267
Pixel Size	3.45 μm × 3.45 μm
Optical Format	1"
Resolution	4096 × 2160
Max. Frame Rate	32 fps@4096 × 2160 Bayer RG 8
Dynamic Range	72.5 dB
SNR	40.1 dB
Gain	0 dB ~20 dB
Exposure Time	Ultra-short exposure mode:1 μs ~ 14 μs Standard exposure mode:15 μs ~ 10 sec
Shutter Mode	Supports automatic exposure, manual exposure, and one-click exposure modes
Mono/Color	Color
Pixel Format	Mono 8/10/12 Bayer RG 8/10/10Packed/12/12Packed YUV422Packed,YUV422_YUYV_Packed RGB8,BGR8
Binning	Support 1× 1, 2 × 2, 4 ×4
Downsampling	Support 1× 1, 2 × 2, 4 ×4
Mirror	Support horizontal Mirror and vertical Mirror

Electrical

Digital I/O	6-pin P7Connector provides Power Supply and I/O:1 optocoupler isolated input (Line0), 1 optocoupler isolated output (Line1), 1 bidirectional configurable non-isolated IO(Line2)
Power Supply	12 VDC, support for USBPower Supply
Typical Power Consumption	3.27 W@5 VDC(USB 3.0Power Supply)
Data Interface	USB 3.0, compatible with USB 2.0

Mechanical

IP Rating	IP30(if Lenses and Cables are installed correctly)
Temperature	Operating Temperature0~50°C, Storage Temperature-30~70°C
Humidity	20%~80% RH Non-condensing
Lens Mount	C-Mount
Dimensions	44 mm×29 mm×59 mm
Weight	About 100 g

General Specifications

Certification	CE,RoHS,KC
Software	MVS or third-party Software compatible with the USB3 Vision protocol
Operating System	Windows XP/7/10/11 32/64bits,Linux 32/64bits and MacOS 64bits
Protocol / Standard	USB3 Vision,GenlCam
