Name: HIKROBOT Standard Series Lighting
Brand: HIKROBOT
SKU: MV-LRDS-34-75-W
Availability: InStock

MV-LRDS-42-65-W

Standard Series Lighting covers Ring Lights, Bar Lights, Line Lights, Area Lights, Coaxial Lights, Dome Lights and other types of Light Sources. It provides standardized and customized Light Source solutions to meet diverse needs and is suitable for various defect detection, size measurement, OCR recognition and other applications.

Product introduction

Functional characteristics

Mechanical is simple, compact, easy to install
Various angles, flexible size
High-quality LED, stable light emission and high brightness

Ordering Model

MV-LRDS-42-65-W

Dimensions

* The data involved in the product may cause Differences due to environmental and other factors, and the company will not bear the consequences arising therefrom.

Ordering Model

MV-LRDS-42-65-W

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Detailed parameters

Ordering Model MV-LRDS-42-65-W

Model

Model	MV-LRDS-42-65-W
Name	Ring LightsMV-LRDS-42-65-W

Performance

Color	White
Wavelength	/
Color Temperature	6000~7000K
Illumination Angle	65°

Optical

Aperture Diameter

Φ18 mm

Electrical

Interface Type	SMR-03V-B
Power	2.0 W

Mechanical

LED Rows	2
Power Cable Length	500 mm
Dimensions	Φ42 × 18 mm
Outer Diameter	Φ42 mm
Temperature	Operating Temperature0~40°C, Storage Temperature-20~60°C
Humidity	20~85%RH No condensation
Diffuser	Included
