Name: HIKROBOT Standard Series Lighting
Brand: HIKROBOT
SKU: MV-LRDS-34-75-W
Availability: InStock

MV-LRDS-90-30-IR940

Standard Series Lighting covers Ring Lights, Bar Lights, Line Lights, Area Lights, Coaxial Lights, Dome Lights and other types of Light Sources. It provides standardized and customized Light Source solutions to meet diverse needs and is suitable for various defect detection, size measurement, OCR recognition and other applications.

Product introduction

Functional characteristics

Mechanical is simple, compact, easy to install
Various angles, flexible size
High-quality LED, stable light emission and high brightness

Ordering Model

MV-LRDS-90-30-IR940

Dimensions

* The data involved in the product may cause Differences due to environmental and other factors, and the company will not bear the consequences arising therefrom.

Ordering Model

MV-LRDS-90-30-IR940

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Detailed parameters

Ordering Model MV-LRDS-90-30-IR940

Model

Model	MV-LRDS-90-30-IR940
Name	Ring LightsMV-LRDS-90-30-IR940

Performance

Color	Infrared
Wavelength	940 nm
Color Temperature	/
Illumination Angle	30°

Electrical

Interface Type	SMR-03V-B
Power	7.8 W

Mechanical

LED Rows	3
Power Cable Length	500 mm
Dimensions	Φ90 × 21 mm
Outer Diameter	Φ90 mm
Aperture Diameter	Φ50 mm
Temperature	Operating Temperature0~40°C, Storage Temperature-20~60°C
Humidity	20~85%RH No condensation
Diffuser	Included
