Name: HIKROBOT 3U Wall-Mount Industrial PC
Brand: HIKROBOT
SKU: MV-IPC-H387H-16G-256G-240
Availability: InStock

MV-IPC-H3C5H-32G-256G2T-241

The 3U Wall-Mount Industrial PC is moderate in size, has good scalability and flexibility. Supports StandardMicro ATX motherboards and Intel® Core™ 6th-13th CPU. It is suitable for installation in space-limited environments and suitable for small and medium visual scenes.

Product introduction

Features

Supports Intel® 12/13/14 Generation Core™ i3/i5/i7/i9 and Pentium®, Celeron® CPU
Provides 2 DDR4 U-DIMM Memory slots, which can be expanded to a maximum of 64G Memory
Provides 1 PCIe ×16, 2 PCIe ×4, 1 PCI expansion slot
Provides 2 Intel network ports, 4 USB3.0 Interfaces, 4 USB2.0 Interfaces
VGA + HDMI+DP display output, Support independent three displays

Ordering Model

MV-IPC-H3C5H-32G-256G2T-241

Dimensions

* The data involved in the product may cause differences due to environmental factors and other factors, and the company will not bear the consequences arising therefrom.

Ordering Model

MV-IPC-H3C5H-32G-256G2T-241

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Detailed parameters

Ordering Model MV-IPC-H3C5H-32G-256G2T-241

Model

Model	MV-IPC-H3C5H-32G-256G2T-241
Name	3U Wall-Mount Industrial PC,mATX-H610,i5-12400,2*16G,256G+2T,300W

Performance

Processor	Supports Intel® CoreTM 12/13/14 generations,i3/i5/i7/i9 and Pentium®, Celeron® CPUs in LGA1700 package,TDP: 65W
Chipset	Intel® H610Chipset,Micro-ATX motherboard
Memory	Provides 2 DDR4 U-DIMMemory slots, 32GB per root, maximum support of 64GB
Storage	Provides 4 7PIN SATA3.0, 1 M.2 Nvme 2242/2280Interface
Operating System	Windows 10/11,Linux

External Interfaces

Network Interface	2 Intel network ports (I226+I219)
USB Interface	4 USB3.0 Interface1, 4 USB2.0 Interfaces Built-in 2 USB2.0 signals (pin form)
Serial Port	1 RS-232/422/485Interface Built-in 1 RS-232/422/485 pin, 4 RS-232 pins
Expansion Interface	1 PCIe x16(PCIe 5.0), 2 PCIe x4(PCIe3.0, x2 signal), 1 PCI expansion slot (32bit)
Display Interface	Supports independent triple displays 1×VGA supports up to 1920×1080@60Hz 1×HDMI maximum support 3840×2160@60Hz 1×DP Maximum support 3840×2160@60Hz
Audio Interface	Mic-In,Line-In,Line-out
GPIO	8-bit GPIO

Electrical

Power Supply	100 ~ 240V AC
Max. Power Consumption	300W

Mechanical

Mounting Method	Wall mounted
Dimensions	351mm × 260mm × 155mm (LWH)
Weight	Net weight approximately 8.0kg
Temperature	Operating Temperature:0 ~ 40 °C,StorageTemperature:-20°C ~ 60°C
Humidity	20%~95% RH No condensation
