Name: HIKROBOT Full Range of Industrial PCs
Brand: HIKROBOT
SKU: MV-IPC-F463H-8G-256G-240
Availability: InStock

MV-VT2000-128G40-NN

The products cover various forms such as rack-mounted, wall-mounted, embedded, and flat-panel all-in-one machines, covering Intel® Core™ 6th-13th CPUs, meeting 1 to 7 different PCIE/PCI expansion requirements and meeting various application needs in the vision industry.

Product introduction

Functional characteristics

Equipped with Intel® Celeron ®J Series Processor, providing powerful computing Performance
Supports multiple IO functions and is simple to operate
Supports multi-channel Gigabit network ports and supports high-speed and stable image transmission
Built-in USBEncryptionInterface for easy on-site deployment and maintenance
All-metal shell, durable and high protective strength
Supports countertop placement, embedded and wall-mounted Mounting Methods, supports VESAStandard

Ordering Model

MV-VT2000-128G40-NN

Dimensions

* Data related to the product may be generated due to environmental factors and other factors Differences , the company will not bear the consequences arising therefrom.

Ordering Model

MV-VT2000-128G40-NN

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Detailed parameters

Ordering Model MV-VT2000-128G40-NN

Model

Model	MV-VT2000-128G40-NN
Name	VT2000 all-in-one, J6412, 8GB +128G SSD;

Performance

Processor	Intel® Celeron® J6412Processor
Memory	8 GB
Storage	128G SSD
Operating System	Windows 10 2021H2, not activated

External Interfaces

Display Interface	1 HDMIInterface(1920 × 1080@60Hz)
Digital I/O	Supports up to 7 isolated inputs and 7 isolated outputs
Network Interface	4 Gigabit Internet ports
USB Interface	2 USB3.0 Interfaces, 2 USB2.0 Interfaces
Serial Port	Supports up to 2 RS-232 Serial Ports, which can be switched to RS-485/RS-422

Electrical

Power Supply	24V DC
Typical Power Consumption	30 W

Display

Screen size	10.1 inch
Resolution	1280 × 800
Backlight	LED
Backlight life	≥30000 hrs
Perspective	85°(R)/ 85°(L)/ 85°(B)/ 85°(T)
Contrast	800:1
Brightness	350 cd/m2(TYP)

Touchscreen

Touchscreen type	Multi-point capacitive Touchscreen
Multi-touch	Support 10-point touch under Windows
Number of strokes	≥ 35 million times
Light transmittance	≥85%
Surface hardness	6 H

Mechanical

Dimensions	255 mm × 170 mm × 63 mm
Weight	About 2 kg
Temperature	Operating Temperature0 ~ 50°C(wind speed 0.7m/s), Storage Temperature-30 ~ 70°C
Humidity	20% ~ 80%RH No condensation
