Name: HIKROBOT Full Range of Industrial PCs
Brand: HIKROBOT
SKU: MV-IPC-F463H-8G-256G-240
Availability: InStock

MV-VT3300-128G40-NN

The products cover various forms such as rack-mounted, wall-mounted, embedded, and flat-panel all-in-one machines, covering Intel® Core™ 6th-13th CPUs, meeting 1 to 7 different PCIE/PCI expansion requirements and meeting various application needs in the vision industry.

Product introduction

Functional characteristics

Equipped with Intel's eighth-generation CPU, providing powerful computing Performance
Supports multiple GPIO functions and is easy to use
Supports multi-channel Gigabit network ports and supports high-speed and stable image transmission
Built-in USB Interface for easy field deployment and maintenance
All-metal casing, durable and well protected
Rich Expansion Interface, which can support extended mechanical hard drives, WIFI, etc.
Easy to install and supports VISAStandard

Ordering Model

MV-VT3300-128G40-NN

Dimensions

* Data related to the product may be generated due to environmental factors and other factors Differences , the company will not bear the consequences arising therefrom.

Ordering Model

MV-VT3300-128G40-NN

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Detailed parameters

Ordering Model MV-VT3300-128G40-NN

Model

Model	MV-VT3300-128G40-NN
Name	VT3000 all-in-one, I3- 8100T, 8GB +128G SSD;

Performance

Processor	Intel® CoreTM i3-8100T
Memory	8 GB
Storage	128G SSD
Operating System	Windows 10, not activated

External Interfaces

Display Interface	1 × HDMI (1920 × 1080)
Digital I/O	Supports 3 digital isolated inputs Support 8 optocoupler isolated outputs
Network Interface	4 × Gigabit Internet Port
USB Interface	4 × USB3.0
Serial Port	4-way RS-232, can be switched to RS-485/RS-422

Electrical

Power Supply	24 VDC
Typical Power Consumption	120 W

Display

Screen size	15.6 inches
Resolution	1920 × 1080
Display area	344.16 mm × 193.59 mm
Backlight	LED
Backlight life	50000 hrs
Perspective	89°(R)/ 89°(L)/ 89°(B)/ 89°(T)
Contrast	1200:1
Brightness	500 cd/m2

Touchscreen

Touchscreen type	Multi-point capacitive Touchscreen
Multi-touch	Support 10-point touch under Windows
Number of strokes	35 million times
Light transmittance	≥87%
Surface hardness	≥6 H

Mechanical

Dimensions	390 mm × 240 mm × 65.8 mm
Weight	4.8 kg
Temperature	Operating Temperature0~50°C, Storage Temperature-30~70°C
Humidity	20% ~ 80% RH No condensation
