Name: HIKROBOT Full Range of Industrial Area Scan Cameras
Brand: HIKROBOT
SKU: MV-CT004G-200GM01-BASE
Availability: InStock

Product introduction

Functional characteristics

Rich ISP processing technology supports manual adjustment of Gamma correction, flat field correction, LUT, black level adjustment, etc.
Various flexible exposure and acquisition methods, the maximum line frequency is 100kHz
Supports bi-directional I/O wiring, flexible input/output configuration
Compact Mechanical design, Camera front and side panels have mounting holes, Flexible installation
Compatible with the Camera Link protocol and GenICamStandard

Ordering Model

MV-CL042-91CM

Dimensions

* The data involved in the product may cause differences due to environmental and other factors, and the company will not bear the consequences.

MV-CL042-91CM

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Detailed parameters

Ordering Model MV-CL042-91CM

Model

Model	MV-CL042-91CM
Name	4k Camera Link linear array Camera, black and white

Performance

Sensor Type	CMOS
Pixel Size	7 μm
Resolution	4096 × 2
Imaging Mode	Support 1-Line/2-TDI
Max. Line Rate	40.5 kHz(Base) , 81 kHz@(Medium), 100 kHz(Full)
Configuration Mode	Base,Medium,Full
Channel Mode	1 × 2,1 × 4,1 × 8
Number of Channels	2/4/8 Taps
Pixel Clock	40 MHz,60 MHz,70 MHz,85 MHz
Dynamic Range	65.6 dB
SNR	40 dB
Gain	Support 1.0x/1.4x/1.6x/2.4x/3.2x
Exposure Time	5 μs ~ 10 ms
Shutter Mode	Support automatic exposure, manual exposure, and one-click exposure; Support fixed Exposure Time and Pulse Width Control Exposure Time
Mono/Color	Black and White
Pixel Format	Mono 8/10/12
Binning	Support 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4
Mirror	Support horizontal Mirror
Trigger Mode	External triggering, internal triggering
External Trigger Mode	Line triggering, frame triggering, line + frame triggering

Electrical

Data Interface	Camera Link (SDRInterface); Supports USB port for firmware upgrades
Digital I/O	12-pin P10Connector provides Power Supply and I/O:4 channels of bidirectional disposable I/O (Line 0/1/3/4);Camera Link provides IO (CC1/CC2/CC3/CC4)
Power Supply	12 ~ 24 VDC
Typical Power Consumption	5.5 W@12 VDC

Mechanical

Lens Mount	M42*1.0,Flange Back Focal Length12 mm; Can be transferred to F ports, C ports and other threaded ports via adapter rings Lenses
Dimensions	62 mm × 62 mm × 36.9 mm
Weight	approx. 238g
IP Rating	IP40 (When Lenses and Cables are installed correctly)
Temperature	Operating Temperature-20 to 55°C, Storage Temperature-30~80°C
Humidity	5%~95% RH No condensation

General Specifications

Software	MVS and Frame Grabbers Control Software
Operating System	Windows XP/7/10/11 32/64bits
Protocol / Standard	Camera Link V2.1,GenICam
Certification	CE,RoHS,KC
