Name: HIKROBOT CL Series Industrial Line Scan Cameras
Brand: HIKROBOT
SKU: MV-CL021-60UM-OCT
Availability: InStock

Product introduction

Functional characteristics

Rich ISP image processing technology, manual adjustment of Gamma correction, flat-field correction, LUT, black level adjustment, etc.
Various flexible exposure and acquisition methods, up to 80 kHz
Supports bi-directional configurable I/O, and inputs/outputs can be flexibly configured
Mechanical is compact and has mounting holes on the front and side panels for flexible installation
Compatible with Camera Link protocol and GenICamStandard

Ordering Model

MV-CL081-41CM

Dimensions

* Data related to the product may be generated due to environmental factors and other factors Differences , the company will not bear the consequences arising therefrom.

Ordering Model

MV-CL081-41CM

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Dimensions drawings can be downloaded from the product manual to view, or contact sales for CAD / PDF drawings.

Detailed parameters

Ordering Model MV-CL081-41CM

Model

Model	MV-CL081-41CM
Name	8K Camera Link, 7μm, black and white

Performance

Sensor Type	CMOS
Pixel Size	7 μm
Resolution	8192 × 1
Imaging Mode	1-Line
Max. Line Rate	20 kHz(Base), 40 kHz(Medium), 80 kHz(Full)
Configuration Mode	Base,Medium,Full
Channel Mode	1 × 2,1 × 4,1 × 8
Number of Channels	2/4/8 Taps
Pixel Clock	40 MHz, 66 MHz, 80 MHz, 85 MHz
Dynamic Range	64.7 dB
SNR	44.3 dB
Gain	1 x/2 x/4 x/8 x
Exposure Time	2 μs ~ 10 ms
Shutter Mode	Supports automatic exposure, manual exposure, and one-click exposure; supports fixed Exposure Time and Pulse Width to control Exposure Time
Mono/Color	Black and white
Pixel Format	Mono 8/10/12
Binning	Support 1 × 1,2 × 2,4 × 4
Mirror	Support Level Mirror
Trigger Mode	External trigger, internal trigger
External Trigger Mode	Line trigger, frame trigger, line + frame trigger

Electrical

Data Interface	Camera Link(SDRInterface); supports USB port for firmware upgrades
Digital I/O	12-pin P10 Connector provides Power Supply and I/O: 4 bidirectional configurable I/Os (Line 0/1/3/4), supporting differential and single-ended IO signals; Camera Link provides IO(CC1/CC2/CC3/CC4)
Power Supply	12 ~ 24 VDC
Typical Power Consumption	5.8 W@12 VDC

Mechanical

Lens Mount	M72*0.75, Flange Back Focal Length 12 mm; can be transferred to F-port Lenses via adapter ring
Dimensions	76 mm × 76 mm × 42.1 mm
Weight	About 320 g
IP Rating	IP40(if Lenses and Cables are installed correctly)
Temperature	Operating Temperature0 ~ 55°C, Storage Temperature-30 ~ 80°C
Humidity	5% ~ 90% RH Non-condensing

General Specifications

Software	MVS and Camera Link compliant Frame Grabbers Control Software
Operating System	Windows XP/7/10/11 32/64bits
Protocol / Standard	Camera Link V1.2,GenICam
Certification	CE,FCC,RoHS,KC
