Name: HIKROBOT Full Range of Industrial Area Scan Cameras
Brand: HIKROBOT
SKU: MV-CT004G-200GM01-BASE
Availability: InStock

Product introduction

Functional characteristics

Supports lossless image compression, Pulse Width controlled exposure
Rich ISP processing technology, supports manual adjustment of Gamma correction, flat field correction, LUT, black level adjustment, etc.
Supports bidirectional I/O wiring, Input/output can be flexibly configured
Compact Mechanical design, Camera front and side panels have mounting holes, Flexible installation
Compatible with GigE Vision V2.0 protocol and GenICamStandard

Ordering Model

MV-CL042-91GC

Dimensions

* The data involved in the product may cause differences due to environmental and other factors, and the company will not bear the consequences arising therefrom.

Ordering Model

MV-CL042-91GC

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Dimensions

Detailed parameters

Ordering Model MV-CL042-91GC

Model

Model	MV-CL042-91GC
Name	4k mesh line array, color

Performance

Sensor Type	CMOS
Pixel Size	7 μm
Resolution	4096 × 2
Max. Line Rate	Basic line frequency:28 kHz@Bayer RG8/Bayer RBGG 8/Mono 8, 14 kHz@Bayer RG10/12/Mono 10/12, 9 kHz@RGB 8/BGR8 HB peak line frequency:80 kHz@Bayer RBGG 8, 40 kHz@Bayer RG8/RGB8 § 2,1 § Support 1.0×, 1.4×, 1.6×, 2.4×, 3.2×
Dynamic Range	65.6 dB
SNR	40 dB
Gain	Support 1.0×, 1.4×, 1.6×, 2.4×, 3.2×
Exposure Time	5 μs~10 ms
Shutter Mode	Support automatic exposure, manual exposure, one-click exposure, pulse controlled exposure
Mono/Color	Color
Pixel Format	Mono 8/10/12 Bayer RG 8/10/12 RGB 8,BGR 8 Bayer RBGG 8
Binning	Support 1 × 1,1 × 2, 1 × 4, 2 × 2, 2 × 4, 4 × 1,4 × 2, 4 × 4
Mirror	Support horizontal Mirror
Trigger Mode	External triggering, internal triggering
External Trigger Mode	Line triggering, frame triggering, line + frame triggering

Electrical

Data Interface	Gigabit Ethernet (1000Mbit/s) Compatible with Fast Ethernet (100Mbit/s)
Digital I/O	12-pin P10Connector provides Power Supply and I/O:4 configurable inputs and outputs (Line 0/1/3/4), supports single-ended/differential
Power Supply	12 ~ 24 VDC, supports PoEPower Supply
Typical Power Consumption	6.6 W@12 VDC

Mechanical

Lens Mount	M42* 1.0, Flange Back Focal Length12 mm; Can be transferred to F ports, C ports and other threaded ports by adapter rings Lenses
Dimensions	62 mm × 62 mm × 41 mm
Weight	approx. 280 g
IP Rating	IP40 (When Lenses and Cables are installed correctly)
Temperature	Operating Temperature-20 to 55°C, Storage Temperature-30~80°C
Humidity	5%~90%RH No condensation

General Specifications

Software	MVS or third party support GigE Vision protocol Software
Operating System	Windows XP/7/10/11 32/64bits, Linux 32/64bits and MacOS 64bits
Protocol / Standard	GigE Vision V2.0,GenICam
Certification	CE,RoHS,KC
