Product introduction

Functional characteristics

Support Pulse Width controlled exposure
Rich ISP processing technology, support manual adjustment of Gamma correction, flat-field correction, LUT, black level adjustment, etc.
Support bidirectional I/O wiring, input/output flexible configuration
Compact Mechanical design, Camera front and side panels have mounting holes, flexible installation
Compatible with GigE Vision V2.0 protocol and GenICamStandard

Ordering Model

MV-CL042-91GM-PL

Dimensions

* Product data may cause differences due to environmental factors and other factors , The company will not bear the consequences arising therefrom.

MV-CL042-91GM-PL

is supplied by an authorized agent from the original factory of Chuanghua Research, supporting prototype testing and batch procurement.

Detailed parameters

Ordering Model MV-CL042-91GM-PL

Model

Model	MV-CL042-91GM-PL
Name	4k mesh port line array, black and white, Photovoltaic industry-specific models

Performance

Sensor Type	CMOS
Pixel Size	7 μm
Resolution	4096 × 2
Imaging Mode	Support 1-Line/2-TDI
Max. Line Rate	28 kHz@Mono 8
Dynamic Range	65.6 dB
SNR	40 dB
Gain	Support 1.0×, 1.4×, 1.6×, 2.4×, 3.2×
Exposure Time	5 μs~50 ms
Shutter Mode	Support automatic exposure, manual exposure, one-click exposure, pulse controlled exposure
Mono/Color	Black and white
Pixel Format	Mono 8
Binning	Support 1 × 1,1 × 2, 1 × 4, 2 × 1,2 × 2, 2 × 4,4 × 1,4 × 2, 4 × 4
Mirror	Support Horizontal Mirror
Trigger Mode	External triggering, Internal triggering
External Trigger Mode	Line triggering, Frame triggering, Line + Frame triggering

Electrical

Data Interface	Gigabit Ethernet (1000Mbit/s) Compatible with Fast Ethernet (100Mbit/s)
Digital I/O	12-pin P10Connector provides Power Supply and I/O:4 configurable inputs and outputs (Line 0/1/3/4), supports single-ended/differential
Power Supply	12 ~ 24 VDC
Typical Power Consumption	5.8 W@12 VDC

Mechanical

Lens Mount	M42* 1.0, Flange Back Focal Length12 mm; Can be transferred to F, C and other threaded ports via adapter rings Lenses
Filter	Infrared Qualcomm (optional)
Dimensions	62 mm × 62 mm × 41 mm
Weight	Approx 280 g
IP Rating	IP40 (When Lenses and Cables are installed correctly)
Temperature	Operating Temperature-10~55°C, Storage Temperature-30~80°C
Humidity	5%~90%RH No condensation

General Specifications

Software	MVS or third-party GigE Vision Protocol Software
Operating System	Windows XP/7/10/11 32/64bits, Linux 32/64bits and MacOS 64bits
Protocol / Standard	GigE Vision V2.0,GenICam
Certification	CE,RoHS,KC
